Products Details

SIGMA 2

Applications:

BAVARIA SIGMA Carbon Dioxide fire extinguisher is effective in fighting flammable liquids and electric fires

  • Suitable for fighting flammable liquids and electric fires Carbon dioxide is a clean agent that leaves no traces, thus ideal for fighting fires involving electronic & hi-tech equipment
  • Allows intermittent and repeated operation
  • Equipped with a brass valve head complete with an overpressure safety valve
  • Equipped with a squeeze-type valve, conical snow horn, and carrying handle
  • High quality surface treatment and red polyester coating
  • Delivered with its speical wall bracket

Technical Specification:



Capacity

2 kg

Fire Classes

34 B

Operating Temperature Range

-30 °C to 60 °C

Cylinder

Seamless steel cylinder

Testing Pressure

310 bar

Bursting Pressure

Minimum 500 bar

Valve Material

Brass valve complete with overpressure safety valve

Discharge fitting

Plastic conical snow horn

Extinguishing Agent

CO2

Paint Finish

Surface treatment and 100% polyester coating

Approx. Gross Weight

6.9 Kg

Approx. Unit Dimension (lxwxh) cm

25.0 x 11.0 x 55.0







Warranty:



Period of Warranty

1 Year

Coverage of the Warranty

Against material failure and production defects

Method of Warranty Coverage

Limited to the replacement of the defected part or product after verification that the failure is covered by the scope of the warranty

Warranty Exclusions

Failures due to misuse, mishandling, or inspection or repair by an unauthorized dealer or entity







TÜV Approved Pressure Vessel

Awarded CE Mark

The Company Certified according to Quality, Environment ISO 9001, ISO 14001 and BS-OHSAS 18001 Management Systems

Bavaria Laboratory Accredited According to the ISO/IEC 17025
